Brand: QSKJ
Model: QS-7812CBD-2A
Parameters:
- Item Type: Step Down Module
- Input Voltage: 8-78V Wide Input Voltage Range
- Maximum Duty Cycle: 85%
- Conversion Efficiency: 93% maximal (efficiency depends on input and output voltage and load size)
- Minimum Differential Pressure: 2V
- Output Voltage Range: 1.5V-20V Adjustable (input voltage must be higher than the output voltage, can not be boosted)
- Output Maximum Current: 2.1A, Maximal
- Output Maximum Power: 20W Maximal working within 12W for a long time.
- Switching Frequency: 100KHz
- Size: Approx. 25 x 55 x 17mm / 1 x 2.2 x 0.7in
Feature:
- 1. High-voltage step-down non-isolated DC-DC converter module with conversion efficiency up to 93%
- 2. The maximum output power is 20W maximal, and it can work within 12W for a long time.
- 3. Adopted of high quality electronic components, and accuracy process, ensure for the durability
- 4. Small body, easy to install and remove
- 5. The output voltage range is 1.5V-20V, it is adjustable
